Power Distribution Unit
1.Product Introduction of Power Distribution Unit OM-SPDU-1608
The Power Distribution Unit OM-SPDU-1608 is a power distribution unit meticulously designed for data centers, server cabinets, and network cabinets. It integrates advanced security network standard protocols and has the function of hot-swapping the entire machine module while it is powered on, truly meeting the actual usage requirements of data centers. Its modular production and customized services can meet the diverse needs of different customers. In addition, it also integrates powerful power distribution functions such as secure network communication protocols, high-precision metering, energy management, and graded protection against short circuits and overcurrents. It has low self-energy consumption, a small size, and a diversified product series. It can be widely applied to multiple fields such as data centers, telecommunications machine rooms, and industrial control, providing users with efficient and reliable power management solutions.
2. Product Parameter (Specification) of Power Distribution Unit OM-SPDU-1608
| project name | Basic description | |
| input | Rated input voltage | AC110V-250V 50/60HZ |
| Maximum load current | 0-63A | |
| Power input mode | Single-phase input, and a three-phase input | |
| Input parameter acquisition | Current, voltage, electic energy ,power(active power, reactive power, apparent power, power factor) | |
| output | output unit | The auxiliary module is 4 output, and the main module supports up to 8 auxiliary modules |
| Rated output voltage | AC220V 50/60HZ | |
| Output parameter acquisition | Current, voltage, electric energy, power (active power, reactive power, apparent power, power factor) | |
| rated output current | 16A | |
| Display part | LCD | A 2-inch LCD display color screen |
| interface parameters | RJ45(NET)1 | 10/100M Etheret access interface |
| Cascade interface | 2 RS485 were used for the device cascade | |
| Sensor interface | 3 external sensor module interfaces | |
| 1 with a USB interface | Plug in the U disk for upgrading the wireless module access of the software system | |
| Other parameters | With 3 physical buttons | 1 upflip button for LCD display; 1 lower tum button for LCD display; One reset button |
| 2s(color LED lights) | Prepare the power supply status indicator and abnormal alam indicator | |
| work enviromment | operating ambient temperature | 0°C~50°C |
| Humidity of working environment | 10-90% | |
3. Product Feature And Application of Power Distribution Unit OM-SPDU-1608
High-precision Electrical Energy Metering: Monitor parameters such as current, voltage, and power in real time to ensure accurate and reliable data.
Intelligent Alarm Function: Support threshold alarms for parameters such as current, voltage, temperature, and humidity, and promptly remind users to handle abnormal situations.
Remote Monitoring and Management: Through the WEB interface or mobile applications, users can monitor the device status and conduct remote control anytime and anywhere.
Modular Design: Support hot swapping, which is convenient for maintenance and upgrading and meets the needs of different customers.
Wide Range of Application Scenarios: Suitable for scenarios such as data centers, server cabinets, and network cabinets, helping users achieve optimized management of power resources.
4. Product Details of Power Distribution Unit OM-SPDU-1608
The Power Distribution Unit OM-SPDU-1608 adopts a modular design and supports the flexible configuration of various sensors. The core of the system is the terminal monitoring host, which centrally manages the data of all sensors. The system supports remote monitoring and management, enabling users to check the device status and alarm information anytime and anywhere through the network.
5. FAQ
Q: How can I remotely monitor the Power Distribution Unit OM-SPDU-1608?
A: Users can enter the device's IP address through the WEB interface or mobile applications to monitor the device status in real time and conduct remote control.
Q: What are the alarm functions of the Power Distribution Unit OM-SPDU-1608?
A: The Power Distribution Unit OM-SPDU-1608 supports threshold alarms for parameters such as current, voltage, temperature, and humidity. Users can set the alarm thresholds according to their actual needs.
